OR-2500H UV
ORIC
With LED UV curing technology, ORIC uv series printer are mostly competitive in the market which characterizes with excellent quality, high stability and easy operation. Environmentally friendly UV ink meets international environment standards. With multilayer printing to build layered effect.
OR-2500H 2.5m UV Roll To Roll And Hybrid All-In-One Printer With 3-12pcs Ricoh Heads
● Technical Characteristics
- Standard extension platform, perfect competent to print both roll and rigid media.
- Cold light LED curing with tiny temperature variation ensures high printing quality.
- Adjustable head height, laser positioning system and movable printing platform result in high-efficiency printing jobs.
- Air-shaft take up system makes more stable paper collecting
- Stable printing technology and ink supply system reduces maintenance cost.
- International ICC standard with profile curve adjustment function.
Material height measurement system
Automatically detect the thickness of the material,adjust the printing height, and meet the printing of 35mm media height.
Front and rear expansion shaft receiving and
discharging system
A more convenient receiving and discharge structure can meet a variety of materials of different thickness specifications.
THK high-precision silent dual rail
Effectively reduce the noise of the working environment and improve the printing accuracy and stability of the car.
High-strength transmission belt device - special
high-strength low-tensile belt, no deviation, no
deformation, long service life
Adopt an international universal ink supply system
to ensure stable ink supply in high-speed printing.
2.5L large ink barrel, automatic ink shortage alarm, timely reminder of ink addition
Double lung function
Automatic adjustment and independent white ink negative pressure system effectively avoid white ink droplets and other problems caused by negative pressure sharing, making white ink printing smoother.
Front and rear extension support frame
Perfectly realize the integrated printing of plates and rolls, and realize the advantages of multi-purpose one machine.
Vacuum suction platform control system
Partition suction platform: choose different regional air cavities according to the size of the material to realize the dual use of plate and coil.
Wide application: coils: soft film · knife scraping cloth · 3P cloth · lamps · canvas · transparent film · car sticker · single transparent · label sticker · PET & PVC · all kinds of cardboard · gold and silver paper · leather · non-woven fabric · wallpaper · wall cloth, etc.; and ultra-transparent glass sticker and other advertising decoration materials to complete color white bronzing, frosted, hollowand other printing schemes!
| Product Specifications: | |
| Product name | 3-12 pcs optional xG5 / G6 |
| Ink Type | UV ink |
| Type | Gray scale piezoelectric inkjet technology |
| WidthxDepthxHeight | stand size : 4300x2100x1550 mm |
| Number of Nozzle | 2400 |
| Nozzle pitch/nozzle row | 1/300 inch |
| Nozzle rows | 8 rows |
| Nozzle Resolution | 300 npi /row 600 npi/2 rows |
| Max. number of colour inks | CMYK / Lc / Lm / W / V |
| Droplet volumes | 6 pl (Single mode) |
| Technical Specifications | |||
| Model | OR2500H | ||
| Print Head | 3-12 pcs optional xG5 / G6 | ||
| Printing Technology | Gray scale piezoelectric inkjet technology | ||
| Acceptable Media | Width | 2530 mm | |
| Thickness | 1-35 mm | ||
| Weight | 200kg paper tube, standard front and rear gas rise shafts | ||
| Printing Width | 1800 MM | ||
| Ink Cartridges | Type | LED UV Ink | |
| Capacity | Continual Ink Supply Systems (2.5L Ink Tank) | ||
| Color | CMYK / Lc / Lm / W / V | ||
| Printing Resolution | Maximum 2400 dpi | ||
| Curing Unit | Dual UV LED Lamps (Water-cooling UV lamp) | ||
| Interface | LAN | ||
| Power Supply | AC 220V ± 10%, 50/60 HZ | ||
| Dimensions(with stand) | stand size : 4300x2100x1550 mm No stand size : 4300x1100x1550 mm | ||
| Weight(with stand) | 1500 kg | ||
| Packing Dimensions | Power on | Temperature:59F to90F [15C to 32C] (68 F [20C]/ Humidity: 35 to 80% (no condensation) | |
| Power off | Temperature:41F to 104 F [5C to 40C]/ Humidity: 20 to 80% (no condensation) | ||
| Weight | USB cable, media clamp, manual, drain bottle, ink cartridges, RIP software, etc. | ||
ORIC brand was founded in Beijing in 2013.
In 2016,ORIC factory was moved from Beijing to Nanjing, officially holding and responsible for operation.
ORIC factory is located in Lishui District, Nanjing, China. Factory covers an area of 88 acres and has a plant area of more than 20,000 square
meters (it will be expanded by 30,000 square meters in the future). ORIC becomes one of the largest inkjet printer production and R&D bases in
China, property rights are fully owned by ORIC.
Factory also have OEM manufacturing services for world-renowned brands : Strong R&D, wide space, design and production capabilities, which
wealready work for some of them.
Nanjing ORIC Digital Technology Co., Ltd. is located in Hefeng Industrial Park, Lishui District, Nanjing City. It has accumulated rich experience in
whole machine design and inkjet control in the field of industrial and civil inkjet printing, and is in the industry leader in green environmental protection,
advanced technology, people-oriented and other aspects. In addition to the advanced functions of the industry's equipment, ORIC UV inkjet series
printers have a more intelligent operation experience, which can help customers solve problems in production faster, and help customers create greater
wealth value with excellent equipment, good reputation, perfect products and services.
As always, our company has won the praise and support of new and old customers with the purpose of good quality, reasonable price and good
reputation. With advanced technology, excellent quality, good reputation and high-quality service, we have established a stable supply relationship
with many merchants, which is well received by the majority of customers. ORIC is committed to promoting the printing industry towards a greener,
more energy-saving and more futuristic direction.
With LED UV curing technology, ORIC uv series printer are mostly competitive in the market which characterizes with excellent quality, high stability and easy operation. Environmentally friendly UV ink meets international environment standards. With multilayer printing to build layered effect.
OR-2500H 2.5m UV Roll To Roll And Hybrid All-In-One Printer With 3-12pcs Ricoh Heads
● Technical Characteristics
- Standard extension platform, perfect competent to print both roll and rigid media.
- Cold light LED curing with tiny temperature variation ensures high printing quality.
- Adjustable head height, laser positioning system and movable printing platform result in high-efficiency printing jobs.
- Air-shaft take up system makes more stable paper collecting
- Stable printing technology and ink supply system reduces maintenance cost.
- International ICC standard with profile curve adjustment function.
Material height measurement system
Automatically detect the thickness of the material,adjust the printing height, and meet the printing of 35mm media height.
Front and rear expansion shaft receiving and
discharging system
A more convenient receiving and discharge structure can meet a variety of materials of different thickness specifications.
THK high-precision silent dual rail
Effectively reduce the noise of the working environment and improve the printing accuracy and stability of the car.
High-strength transmission belt device - special
high-strength low-tensile belt, no deviation, no
deformation, long service life
Adopt an international universal ink supply system
to ensure stable ink supply in high-speed printing.
2.5L large ink barrel, automatic ink shortage alarm, timely reminder of ink addition
Double lung function
Automatic adjustment and independent white ink negative pressure system effectively avoid white ink droplets and other problems caused by negative pressure sharing, making white ink printing smoother.
Front and rear extension support frame
Perfectly realize the integrated printing of plates and rolls, and realize the advantages of multi-purpose one machine.
Vacuum suction platform control system
Partition suction platform: choose different regional air cavities according to the size of the material to realize the dual use of plate and coil.
Wide application: coils: soft film · knife scraping cloth · 3P cloth · lamps · canvas · transparent film · car sticker · single transparent · label sticker · PET & PVC · all kinds of cardboard · gold and silver paper · leather · non-woven fabric · wallpaper · wall cloth, etc.; and ultra-transparent glass sticker and other advertising decoration materials to complete color white bronzing, frosted, hollowand other printing schemes!
| Product Specifications: | |
| Product name | 3-12 pcs optional xG5 / G6 |
| Ink Type | UV ink |
| Type | Gray scale piezoelectric inkjet technology |
| WidthxDepthxHeight | stand size : 4300x2100x1550 mm |
| Number of Nozzle | 2400 |
| Nozzle pitch/nozzle row | 1/300 inch |
| Nozzle rows | 8 rows |
| Nozzle Resolution | 300 npi /row 600 npi/2 rows |
| Max. number of colour inks | CMYK / Lc / Lm / W / V |
| Droplet volumes | 6 pl (Single mode) |
| Technical Specifications | |||
| Model | OR2500H | ||
| Print Head | 3-12 pcs optional xG5 / G6 | ||
| Printing Technology | Gray scale piezoelectric inkjet technology | ||
| Acceptable Media | Width | 2530 mm | |
| Thickness | 1-35 mm | ||
| Weight | 200kg paper tube, standard front and rear gas rise shafts | ||
| Printing Width | 1800 MM | ||
| Ink Cartridges | Type | LED UV Ink | |
| Capacity | Continual Ink Supply Systems (2.5L Ink Tank) | ||
| Color | CMYK / Lc / Lm / W / V | ||
| Printing Resolution | Maximum 2400 dpi | ||
| Curing Unit | Dual UV LED Lamps (Water-cooling UV lamp) | ||
| Interface | LAN | ||
| Power Supply | AC 220V ± 10%, 50/60 HZ | ||
| Dimensions(with stand) | stand size : 4300x2100x1550 mm No stand size : 4300x1100x1550 mm | ||
| Weight(with stand) | 1500 kg | ||
| Packing Dimensions | Power on | Temperature:59F to90F [15C to 32C] (68 F [20C]/ Humidity: 35 to 80% (no condensation) | |
| Power off | Temperature:41F to 104 F [5C to 40C]/ Humidity: 20 to 80% (no condensation) | ||
| Weight | USB cable, media clamp, manual, drain bottle, ink cartridges, RIP software, etc. | ||
ORIC brand was founded in Beijing in 2013.
In 2016,ORIC factory was moved from Beijing to Nanjing, officially holding and responsible for operation.
ORIC factory is located in Lishui District, Nanjing, China. Factory covers an area of 88 acres and has a plant area of more than 20,000 square
meters (it will be expanded by 30,000 square meters in the future). ORIC becomes one of the largest inkjet printer production and R&D bases in
China, property rights are fully owned by ORIC.
Factory also have OEM manufacturing services for world-renowned brands : Strong R&D, wide space, design and production capabilities, which
wealready work for some of them.
Nanjing ORIC Digital Technology Co., Ltd. is located in Hefeng Industrial Park, Lishui District, Nanjing City. It has accumulated rich experience in
whole machine design and inkjet control in the field of industrial and civil inkjet printing, and is in the industry leader in green environmental protection,
advanced technology, people-oriented and other aspects. In addition to the advanced functions of the industry's equipment, ORIC UV inkjet series
printers have a more intelligent operation experience, which can help customers solve problems in production faster, and help customers create greater
wealth value with excellent equipment, good reputation, perfect products and services.
As always, our company has won the praise and support of new and old customers with the purpose of good quality, reasonable price and good
reputation. With advanced technology, excellent quality, good reputation and high-quality service, we have established a stable supply relationship
with many merchants, which is well received by the majority of customers. ORIC is committed to promoting the printing industry towards a greener,
more energy-saving and more futuristic direction.
